The function of the transmission filter is to filter foreign impurities, filter clutch friction plates, steel plates and friction material fibers that are constant in friction, as well as filter debris generated by friction of metal parts such as gears, steel belts, chains, etc.
filters, O-rings, gaskets, sealants and other parts that can be used in the maintenance process, which can meet the needs of more than 95% of the models on the market. required.
1) Filter foreign impurities, such as dust in the air, into the gearbox through the ventilation valve;
2) Filter the friction material fibers produced by friction between clutch friction plates and steel plates;
3) Filter the mixture produced by plastic parts such as oil seals and sealing rings in high-temperature working environments;
4) Filter debris generated by friction of metal parts such as gears, steel belts, chains, etc.;
5) Filter the products of the high-temperature oxidation process of the gearbox oil itself, such as various organic acids, coke asphalt and carbides, etc.
During the operation of the gearbox, the oil in the gearbox will continue to become dirty. The function of the gearbox oil filter is to filter out the impurities produced by the gearbox during operation and supply clean gearbox oil to various sports. As well as the solenoid valve and oil circuit, they play the roles of lubrication, cooling, cleaning, rust prevention, and anti-friction, thereby protecting parts, ensuring transmission performance, and extending the service life of the transmission.
Under normal circumstances, automobile automatic transmissions need to replace automatic transmission fluid (ATF) every two years or every 40,000 kilometers traveled. Transmission oil will oxidize and deteriorate if it works at high speed and high temperature for a long time, thereby aggravating the wear of mechanical parts and even damaging the internal parts of the transmission in severe cases. If the transmission oil is not replaced for a long time, the transmission oil will become thicker, which will easily block the transmission heat dissipation pipe, causing the transmission oil temperature to be too high and aggravating wear. Failure to replace the transmission oil for a long time may also cause the vehicle to start when it is cold. There is no power, and the vehicle may slip slightly while driving.
The gearbox oil flows in the gearbox. While lubricating the machine parts, it also washes away the impurities attached to the surface of the machine parts. When the washed impurities flow through the filter with the oil, the impurities will be filtered out, and the filtered clean oil will re-enter the lubrication system for circulation. But the premise is that your filter must have a good filtering effect. After long-term use of the filter, the filtration effect will be greatly reduced, and the oil permeability will become worse and worse. The disadvantages of changing the transmission oil without changing the transmission filter are as follows:
1) The metal debris and impurities on the transmission filter have not been cleaned, and the filtration and passability of the filter have not been improved. If the transmission oil pressure is insufficient, it will cause slow gear shifting, slight sluggishness, and heavy transmission. Otherwise, the transmission will not be able to shift into gear and the vehicle will not be able to drive;
2) Impurities on the filter screen may enter the new oil and re-participate in the circulation of the transmission oil, quickly contaminating the new oil and reducing the effect of oil change;
3) The most frightening thing is that if the filter is clogged, the transmission oil will be supplied directly from the filter's bypass valve to the transmission without going through the filter. In this way, the transmission filter will not be able to remove the transmission oil at all. The function of filtration greatly reduces the service life of the gearbox.
