The auxiliary hook of the Zoomlion crane is driven by the auxiliary drum, and the boom tip pulley is used during the auxiliary pole operation to quickly lift lighter goods to a higher position. The hoisting rope uses an inverted taper sleeve and a cylindrical pin to connect the pull rod of the auxiliary hook, and the pull rod lifts the hook through a pressure bearing. The hook is hinged to the hook body with a cylindrical pin. Therefore, the hook and the hook body can rotate around the pull rod together, and can rotate around a single auxiliary winch. A one-way clamping plate is installed on the auxiliary hook to prevent the spreader from unhooking on its own.
So, how to disassemble the small hook of Zoomlion 25-ton crane?
Firstly, behind the traction beam of the Zoomlion 25-ton crane, set a jack between the plate base and the rear end of the hook tail frame of the coupler. The top of the golden jack is connected to the rear end of the hook tail frame. The bottom of the jack passes through The place where the party iron and the rear slave plate joint meet.
Then, pressurize the jack and move the hook tail frame forward, while the buffer is in a compressed state.
Finally, disassemble the hook tail pin and disassemble the hook head, and you are done.
