The main components of a turbocharger:

1. Shell system: 2. Sealing system: 3. Wheel and shaft system: 4. Insulation system: 5. Thrust system: 6. Fastening system: 7. Bearing system: 8. Bypass valve system.

(1) Shell system:

Compressor casing

Bearing body

turbine box

(2) Wheel and shaft system:

turbine rotor

compressor impeller

thrust bearing

(3) Thrust system:

Thrust sleeve

(4) Thermal insulation system

Thermal insulation cover

(5) Bearing system

Bearing sleeve

(5)Sealing system:

sealing ring

Back plate

Gland

0-shaped circle

(6) Fastening system:

Pressure plate

screws

(7) Bearing system:

Bearing sleeve

(8) Bypass valve system:

Actuator assembly

Internal structural parts of the turbocharger:

01 turbine box

02 steel wheel

03 sealing ring

04Thermal insulation cover

05. Hot end pressure plate

06. Screws

07. Back-up ring

08. Bearing sleeve

09. Bearing body

10. Thrust piece

11. Thrust bearing

12. Oil baffle

13. Thrust sleeve

14. Sealing sleeve

15. Type 0 sealing ring

16. Type 0 sealing ring

17. Back plate

18. Gasket

19. Screws

20. Screws

21. Cold end pressure plate

22. Compressor casing

23. Nameplate

24. Rivets

25. Impeller

26. Locking nut
